Features & Material Excellence
High-Strength Housing:
Fabricated from reinforced steel, offering enhanced torsion resistance and structural integrity.
01
Precision-Geared System:
Case-hardened spiral bevel gear set ensures quiet operation, minimal energy loss, and high torque capacity.
02
Optimized Differential:
Provides excellent traction and stability across varied road surfaces.
03
Advanced Lubrication Design:
Promotes efficient heat dissipation and reduces wear on moving components.
04
Corrosion-Resistant Finish:
Multi-layer coating protects against rust and environmental damage.
05
Technical Parameters
|
Parameter Item |
Specification |
Unit |
|
Rated Load Capacity |
10-20 |
T |
|
Reduction Ratio |
3.42-6.72 |
- |
|
Main Reducer Type |
Spiral Bevel Gear / Hypoid Gear |
- |
|
Axle Housing Material |
42CrMo |
- |
|
Gear Material |
18CrNiMo7-6 |
- |
|
Maximum Input Torque |
2500-5000 |
N·m |
|
Working Temperature Range |
-30 to 110 |
℃ |
Key Advantages
- Fuel Efficiency: Streamlined power transfer lowers energy consumption.
- Low Noise Output: Advanced gear design and assembly reduce operational sound levels.
- Minimal Maintenance: Sealed unit and durable parts decrease servicing frequency.
- Adaptability: Compatible with various vehicle configurations and operating environments.
Typical Applications
- Freight and logistics trucks
- Intercity and coach buses
- Mining and construction vehicles
- Agricultural and forestry machinery
Manufacturing & Process Technology
Our axles are produced using automated forging, CNC gear cutting, and computer-aided grinding to ensure micron-level precision. Each unit undergoes rigorous bench testing, including fatigue endurance and noise-vibration-harshness (NVH) checks, to guarantee conformity to international quality standards.
Production Workflow
Material selection → Forging & machining → Gear shaping & hardening → Assembly → Dynamic testing → Surface treatment → Quality inspection → Packaging
Services
We offer customized axle solutions, OEM/ODM support, technical consultation, and after-sales assistance. Our global service network provides timely maintenance guidance and spare parts supply.
FAQ
Q: What is the typical lifespan of this drive axle?
A: Under normal conditions, it operates reliably for over 500,000 km with proper maintenance.
Q: Can the gear ratio be customized?
A: Yes, we provide tailored gear ratios to match specific vehicle requirements.
Q: Is the axle compatible with retrofitting?
A: It is designed for easy integration with common chassis systems.
Q: What warranties are provided?
A: We offer a 24-month warranty covering manufacturing defects.
